◆52 Gas Regulator/Model:GT-026-52
Medium-sized regulator is applicable to all welding cuts,building and installation and so on.The design of double pressure has provided convenience for reading of gas cylinder pressure and operating pressure. The gauge ：the scope of application of kpa single scale’s reading is much wider and more visualized.The main body is forged and fashioned from high-quality brass and the upper cover is manufactured from high-quality high-strength zinc alloy ; and external relief valves are equipped and sintered bronze filters is in stalled at the air inlet.
Model | Applicable Gas | Max. Input Pressure | Max. Output Pressure | Flow | Inlet | Outlet |
GT-026-52 | OXYGEN | 30000kpa | 10000kpa | 40m3/h | G 5/8 | 5/8-18UNF |
AR | 30000kpa | 10000kpa | 32 L/min | G 5/8 | 5/8-18UNF | |
SINGLE SURFACE ARGON | 30000kpa | 10000kpa | G 5/8 | 5/8-18UNF | ||
ACETYLENE | 2700kpa | 150kpa | 5m3/h | G 5/8-LH | 5/8-18UNF-LH | |
SING TABLE | 2700kpa | 0kpa | 10m3/h | 7/8-14UNF-LH | 5/8-18UNF-LH |
