JSCUT-100 is high quality air cooling plasma power source for CNC cutting which has high pierce capability and can achieve high verticality. JSCUT-100 adopts the full-bridge soft-switching technology, current can be adjustable between 35A-100A steplessly, it can make cutting operation more controllable. It is heavy duty, 100% duty circle, and it has built in multi protections for over current, over voltage, over air-pressure, over temperature etc, allows you to work 24 hours continuously.
Technical Parameters
Rated Input Voltage | V | 3x380(50Hz/60Hz) +/- 10% |
Rated Input Power | KVA | 16 |
Cutting Current | A | 35-100 |
Duty Circle | - | 100A/100% |
Cutting Thickness | mm | According to material. |
Pierce Thickness | mm | 16 |
Quality Cutting | mm | 20 |
Max. Cutting | mm | 38 |
Working gas | - | air |
Gas Volume | L/min | 200 |
Working gas Pressure | MPa | 0.4 |
Cooling Method | - | air |
Weight of Machine | kg | 45 |
Size of Machine | cm | 60x31x56 |
【HC1003 Torch Part Name and Code】
Cutting Method | Current (A) | Electrode | Nozzle | Protective Cap | Gas Tube | Copper Sleeve |
Straight Cutting | 35-60 | 131010 | 132106 | 133210 | 134010 | 135013 |
65-100 | 132110 |
